Internet of Things Based Solar Panel Cooling Effectiveness: Automatic and Manual Pump Comparison
Abstract
The importance of photovoltaic (PV) systems is emphasized by the increasing demand for renewable energy. However, the increase in temperature on the surface of PV panels greatly affects the performance of PV systems. The impact of IoT-based cooling systems on PV systems is the focus of this study. We applied a comparative experimental design with three configurations: baseline (no cooling), manual (pump activated every 60 minutes for 5 minutes), and automatic (pump activated when the panel temperature 40°C or higher for 5 minutes). The PV panels were equipped with copper pipe cooling, an ESP32 microcontroller, RS485 Modbus communication, and IoT monitoring using Blynk, and were tested outdoors from 08:00 to 16:00. Data collected from the PV (voltage, current, Pmax) was recorded every 5 minutes and analyzed. Our research results show that automatic cooling produces the highest temperature reduction compared to manual cooling. Automatic cooling increases daily PV production by 69.19%, which is equivalent to a 36.05% increase in clean energy. However, the net efficiency of manual cooling is much lower due to fixed-interval pump operation. Therefore, under clear sky conditions, the results show that an automatic cooling system with IoT enables better PV module performance by providing better thermal stabilization. However, considering that this study was only conducted for one day, further research under various weather conditions is needed to prove long-term reliability and consistency.
Keywords
Full Text:
PDFReferences
A. C. Adi, “Konsumsi Listrik Masyarakat Meningkat, Tahun 2023 Capai 1.285 kWh/Kapita, 2024.” Accessed: May 11, 2025. [Online]. Available: https://www.esdm.go.id/id/media-center/arsip-berita/konsumsi-listrik-masyarakat-meningkat-tahun-2023-capai-1285-kwh-kapita
“SEBAIKNYA KONSUMEN TAHU TENTANG PLTS & Biodiesel,” Modul Pembelajaran. [Online]. Available: https://energiterbarukan.org/assets/2020/10/BUKU-PLTS-DAN-BIODISEL.pdf
F. Afif and A. Martin, “Tinjauan Potensi dan Kebijakan Energi Surya di Indonesia,” J. Engine Energi, Manufaktur, dan Mater., vol. 6, no. 1, p. 43, 2022, doi: 10.30588/jeemm.v6i1.997.
V. Dwisari, S. Sudarti, and Y. Yushardi, “Pemanfaatan Energi Matahari: Masa Depan Energi Terbarukan,” Opt. J. Pendidik. Fis., vol. 7, no. 2, pp. 376–384, 2023, doi: 10.37478/optika.v7i2.3322.
I. Anshory et al., “Monitoring solar heat intensity of dual axis solar tracker control system: New approach,” Case Stud. Therm. Eng., vol. 53, no. October 2023, p. 103791, 2024, doi: 10.1016/j.csite.2023.103791.
J. Jamaaluddin et al., “Heat Transfer Management of Solar Power Plant for Dryer,” Int. J. Eng. Appl., vol. 12, no. 3, p. 195, May 2024, doi: 10.15866/irea.v12i3.23959.
J. Jamaaluddin, I. Anshory, S. B. Sartika, Khoiri, and Mardiyono, “Utilizing Solar Power for Communication and Illumination in Disaster Zones,” Acad. Open, vol. 8, no. 2, Aug. 2023, doi: 10.21070/acopen.8.2023.7236.
M. R. Pratama, J. Jamaaluddin, and I. Sulistiyowati, “Electric Bicycle Battery Charging System Design Using Solar Panel,” JEEE-U (Journal Electr. Electron. Eng., vol. 8, no. 2, pp. 71–81, 2024, doi: 10.21070/jeeeu.v8i2.1698.
N. Atikah, B. Pramono Jati, and D. Nugroho, “Analisis Pengaruh Suhu Terhadap Daya Output pada Panel Surya Monocrystalline dan Polycrystalline 50 Wp,” Cyclotron, vol. 7, no. 02, pp. 18–25, 2024, doi: 10.30651/cl.v7i02.21822.
A. F. Aditya and A. Ulinuha, “Analysis of Photovoltaic Panel Performance Integrated with the Grid in a Load-Sharing Scheme,” ELKHA, vol. 17, no. 1, pp. 53–60, Apr. 2025, doi: 10.26418/elkha.v17i1.91191.
J. T. Mesin, F. Sains, and U. B. Belitung, “PENGARUH PENDINGINAN PANEL SURYA TERHADAP EFISIENSI DAYA KELUARAN,” vol. 10, no. 1, pp. 36–40, 2024.
V. F. Abast, H. J. R. Sumarauw, J. C. Kewas, F. Teknik, P. Studi, and T. Mesin, “ANALISA SUHU PERMUKAAN TERHADAP DAYA OUTPUT SOLAR CELL 10 WP TIPE MONOCRYSTALLINE Viktor,” vol. 3, no. 2, pp. 1–8, 2023.
R. Y. Prasetiya, S. A. Adilla, M. F. K. Farid, E. A. Hakim, and D. Suhardi, “Performance Analysis of the 1 MW Rooftop Solar Power Generation System at the Karawang,” JEEE-U (Journal Electr. Electron. Eng., vol. 8, no. 2, pp. 60–70, 2024, doi: 10.21070/jeeeu.v8i2.1685.
A. Husai Siregar and P. Harahap, “Analisis Pengaruh Suhu dan Angin Terhadap Daya dan Efisiensi Panel Surya 100 Wp,” J. Tek. Elektro dan Komput., vol. 13, no. 02, pp. 97–102, Aug. 2024, doi: 10.35793/jtek.v13i02.55319.
J. Harie Satiyadi, R. Muhamad Hudan, and A. Asrori, “Analisis Pengaruh Suhu Panel Surya Terhadap Output Panel Performance,” J. Mech. Eng., vol. 1, no. 1, pp. 42–51, 2024, doi: 10.47134/jme.v1i1.2189.
Suwarti, Wahyono, and B. Prasetiyo, “Analisis Pengaruh Intensitas Matahari, Suhu Permukaan & Sudut Pengarah Terhadap Kinerja Panel Surya,” Eksergi, vol. 14, no. 3, p. 78, 2019, doi: 10.32497/eksergi.v14i3.1373.
E. P. LAKSANA, O. SANJAYA, S. SUJONO, S. BROTO, and N. FATH, “Sistem Pendinginan Panel Surya dengan Metode Penyemprotan Air dan Pengontrolan Suhu Air menggunakan Peltier,” ELKOMIKA J. Tek. Energi Elektr. Tek. Telekomun. Tek. Elektron., vol. 10, no. 3, p. 652, 2022, doi: 10.26760/elkomika.v10i3.652.
Z. R. Tahir et al., “Effect of Temperature and Wind Speed on Efficiency of Five Photovoltaic Module Technologies for Different Climatic Zones,” Sustain., vol. 14, no. 23, 2022, doi: 10.3390/su142315810.
F. Shaik, S. S. Lingala, and P. Veeraboina, “Effect of various parameters on the performance of solar PV power plant: a review and the experimental study,” Sustain. Energy Res., vol. 10, no. 1, 2023, doi: 10.1186/s40807-023-00076-x.
R. Pido, “ANALISA PENGARUH KENAIKAN TEMPERATUR PERMUKAAN SOLAR CELL TERHADAP DAYA OUTPUT,” Gorontalo J. Infrastruct. Sci. Eng., vol. 2, no. 2, p. 24, Oct. 2019, doi: 10.32662/gojise.v2i2.683.
N. M. Janna and D. A. Widodo, “Analisis Karakteristik Modul Panel Surya Dengan Sistem Pendingin Air,” J. Fokus Elektroda Energi List. Telekomun. Komputer, Elektron. dan Kendali), vol. 6, no. 1, p. 37, 2021, doi: 10.33772/jfe.v6i1.16200.
Y. M. Al-Sharo, K. Al Smadi, T. Al Smadi, and Y. K. N., “Optimization of Stable Energy PV Systems Using the Internet of Things (IoT),” vol. 31, no. 1, pp. 127–137, 2024, doi: http://doi.org/10.25130/tjes.31.1.11.
I. Anshory, A. Wisaksono, J. Jamaaluddin, and A. Fudholi, “Implementation of ARM STM32F4 microcontroller for speed control of BLDC motor based on bat algorithm,” Int. J. Power Electron. Drive Syst., vol. 15, no. 1, pp. 127–135, 2024, doi: 10.11591/ijpeds.v15.i1.pp127-135.
I. Sulistiyowati, A. I. Muzaqi, M. S. Maulana, M. T. Alimova, and Supardi, “Revolutionizing package delivery with IoT-based smart boxes: Solving the Dilemma of missed deliveries,” 2024, p. 020006. doi: 10.1063/5.0220240.
S. Syahrorini, A. Rifai, D. H. R. Saputra, and A. Ahfas, “Design Smart Chicken Cage Based On Internet Of Things,” IOP Conf. Ser. Earth Environ. Sci., vol. 519, p. 012014, Jul. 2020, doi: 10.1088/1755-1315/519/1/012014.
A. Ahfas, M. B. Ulum, D. H. R. Saputra, and S. Syahrorini, “Automatic Spray Desinfectant Chicken with Android Based on Arduino Uno,” IOP Conf. Ser. Earth Environ. Sci., vol. 519, no. 1, 2020, doi: 10.1088/1755-1315/519/1/012013.
A. Wisaksono and C. Aswar Ragil, “Design and Development of Parking Motor Parking Information System at Muhammadiyah University , Sidoarjo Design and Development of Parking Motor Parking Information System at Muhammadiyah University , Sidoarjo”, doi: 10.1088/1757-899X/874/1/012015.
S. D. Ayuni, S. Syahrorini, and J. Jamaaluddin, “Lapindo Embankment Security Monitoring System Based on IoT,” Elinvo (Electronics, Informatics, Vocat. Educ., vol. 6, no. 1, pp. 40–48, 2021, doi: 10.21831/elinvo.v6i1.40429.
S. D. Ayuni, S. Syahrorinni, and J. Jamaaluddin, “Sosialisasi Aplikasi Monitoring Keamanan Tanggul Lapindo via Smartphone di Desa Gempolsari,” J. Pengabdi. Masy. Progresif Humanis Brainstorming, vol. 5, no. 1, pp. 154–161, 2022, doi: 10.30591/japhb.v5i1.2717.
DOI: https://doi.org/10.33387/protk.v13i1.10741
